Description
Product name: New granule packing machine
Model: LT-61XK
Bag type: three side seal/back seal/four side seal
Packing speed: 30-100 bags/min
Filling weight: 1-100g
Type of measurement: Volume measurement
Film type: PP, PE, PS, EVA, PET, PVDC+PVC, OPP+ composite CPP etc
Quantitative: Volume measuring cup
Bag size: length 30-170mm width 30-130mm
Filling system: measuring cup feeding
Sealing method: heat seal
Total power: AC220V/ 50Hz /1.4kw
Outer packing size: 810*630*1550mm
Weight: 300kg
Electrical configuration: touch screen/PLC/ servo/AC contactor/relay/button/solid state relay/temperature control meter/stepping motor/optical eye/air switch/switching power supply/frequency converter/variable frequency motor
Application: Suitable for the measurement and packaging of granular items, such as peanuts, seeds, coffee, sunflower seeds, etc.
Function: can automatically complete the material, bag making, measuring, filling, sealing, cutting, counting, can be configured according to the needs of the code function.
PLC control with touch screen operation, drive stepper motor control bag length, stable performance, easy adjustment, accurate detection.
Intelligent temperature controller, PID adjustment, ensure that the temperature error range is controlled within 1℃.
Applicable industries: Applicable to food, medicine, chemical, cosmetics and other industries
Degree of automation: Fully automatic
Warranty period: One year warranty, lifetime maintenance
Core selling point: new on the new, beautiful bag, stable performance, fast speed, price concessions
